eBT-DES

Enemy GCS location detection and identification drones

Detect and identify the enemy's GCS location and send the enemy's GCS location by EO/IR

WHAT IS eBT-DES?

eBT-DES is an advanced drone detection system designed to create a secure environment against drone threats.

Utilizing RF spectrum analysis, it detects drone control signals in real-time and accurately tracks their locations. The system employs directional antenna arrays and TDOA technology for precise direction finding and position estimation. With multi-target tracking capability, eBT-DES can monitor multiple drones simultaneously.

It serves various sectors including defense, law enforcement, and civil applications, enhancing overall security.

Specifications

Recognizable Signal Types

Interference sources and drone remote control signals

Detection Frequency Bands

2.4GHz, 5.2GHz and 5.8GHz

Detection Range

≥ 3 km

Detection Angle

Horizontal/Vertical Angle ≤90°

Detection Accuracy

≤3° (RMS)

Frequency Resolution

≤0.5 MHz

Time Resolution

≤0.05 ms

Size

1205 x 980 x 278 mm (unfolded)
455 x 263 x 248 mm (folded)

Weight

6.63kg

Operating Temperature

-25˚C ~ 60˚C

Storage Temperature

-30˚C ~ 60˚C

IP Rating

IP65
